Sheet Metal Fabrication

Worthy Hardware is a premier sheet metal fabrication company, fully-equipped sheet metal shop with welding, shearing, punching facilities. We also carry a large inventory of stainless steel(1-12mm), aluminum(1-10mm), and galvanized sheet (1-20mm) stock in order to continuously provide immediate service. Our custom precision sheet metal fabrication services offer a cost-effective and on-demand solution for your manufacturing needs.

What is Sheet Metal Fabrication?

Sheet Metal Fabrication is one of the most necessary types of modern industrial manufacturing. It is the process of turning flat sheets of steel or aluminium into metal structures or products, by cutting, punching, folding and assembling. Sheet metal fabrication is used in pretty much every sort of manufacturing field, notably in medical equipment, computers, electronics and appliances.

Fabrication services range from low-volume prototype to high-volume production runs with significant cost savings.

What are the advantages for sheet metal fabrication?

Advantages for Sheet Metal Fabrication

Efficiency and Accuracy

Through the use of the latest CAD/CAM and CNC technology and manufacturing equipment our sheet metal fabrication process is guaranteed to be efficient as well as accurate

Durability and Malleability

Sheet metals are strong enough to withstand high pressures, yet they are malleable. They can be formed into almost any shape, which means they are an ideal material for innovative architects and designers to work

Diversity Material

Sheet metal is of a low weight and thin gauge making transport and delivery of the product straightforward and cost effective.

Easily Repairable

Repairs can be carried out in a simple and straightforward way by removing an individual metal sheet from a structure and replacing it without having to dismantle an entire construction.

Low Cost

For all the reasons above – efficiency, durability, ease of transport and design – sheet metal fabrication offers customers a high quality yet inexpensive route to obtaining a product they can work with.

Choose the right material for your Sheet Metal Fabrication parts?

Worthy Hardware could make custom sheet metal fabrication services offer a cost-effective and on-demand solution for your manufacturing needs. Fabrication services material range from metal to plastic runs in a variety of sheet metal fabrication processes.

Materail Brand Thickness StrengthMaterial Characteristic Surface
Stainless SteelSS304/SS301/SS4300.1-10mm53kgf/mm2Not easy to rustBrushing/Polish
Cold Rolling SteelSPCC/CRS0.25-3.2mm28kgf/mmEasy to rust and damage the surfaceApply for paint and powder coating parts
AluminumAlu1100/1050/5052/6061/60630.3-20mm

 A5052≥25kgf/mm2                     A1100≥1007kgf/mm2  A6061T6=27kgf/mm2

Easy to oxidize and corrodeGood for anodizing,brushing,sand-blasting,alodine
Hot-Dip GalvanizingSPGC 0.4-3.2mm40~55kgf/mm2Not easy to rustDont need to plating again.
Hot Rolling SteelSPHC/HRS1.4-6.0mm41~52kgf/mm2Easy to rustApply for paint and powder coating parts
Copper

C1020/C1100/C2100/C2200/C2300

/C2400/C2600

0.3mm1/4H/--1/2HEasy to conductiveGood for brass,tin.nickel

Sheet Metal Fabrication Finishes

Finishing is a most important step in fabrication. Finishing is the final step in preparing metal products for use. Finishing makes products more resistant to corrosion, adds an extra layer of durability and makes surfaces look their best. Within those types of aluminum, stainless steel, steel. Listed on above, there are many sheet metal finishing options. Finishing provides higher electrical, chemical or tarnish resistance. A product’s finish is determined by its use. Here are some factors considered when choosing a finishing method.

Aluminum Material Series

Material SurfaceChoose the right surface to your sheet metal fabricationFinish Example
Aluminum Material SeriesAs Machined~125 RA µin (3.2 RA µm). Minor tool marks will be visible on the part.
Bead BlastedBead blasting adds a uniform matte or satin surface finish on a machined part, removing all tool marks. Mainly used for aesthetic purposes.
Anodized Clear or Color Anodizing adds a thin, hard, non-conductive ceramic coating on the surface of aluminum parts, increasing their corrosion and wear resistance. Available in a variety of colors
Hard Anodized Hardcoat anodizing produces a thicker ceramic coating providing excellent corrosion and wear resistance. for functional applications.
Power CoatedPowder coating adds a thin layer of strong, wear and corrosion resistant protective polymer paint on the surface of a part. Available in a large range of colors.
BrushingBrushing is produced by polishing the metal with grit resulting in a unidirectional satin finish.
Painted Painting adds a thin layer of strong ,wear and corrosion resistant protective polymer paint on the surface of a part. Availabe in a large range of colors
AlodineAlodine is an inexpensive solution to prevent aluminum from oxidizing. There are two types: Conductive and Non-Conductive.

Stainless Steel Material Series

Material SurfaceChoose the right surface to your Sheet Metal Fabrication partsFinish Example
Stainless Steel Material SeriesAs Machined~125 RA µin (3.2 RA µm). Minor tool marks will be visible on the part.
BrushingBrushing is produced by polishing the metal with grit resulting in a unidirectional satin finish.
PolishedPolishing can make products achieve very glossy and smooth surface roughness
Black OxidedBlack Oxided is a conversion coating for ferrous and non-ferrous materials
PassivatedPassivation is the process of treating or coating a metal in order to reduce the chemical reactivity of its surface.
 Chromate PlatedIt is used for decorating purpose,chrome plating can also serve as a layer of protect in as well. It is applied to metal objects when three is an increased opportuntiy for corrosion to occur

Steel & Alloy Steel Material Series

Material SurfaceChoose the right surface to your Sheet Metal Fabrication partsFinish Example
Steel & Alloy Steel Material SeriesAs Machined~125 RA µin (3.2 RA µm). Minor tool marks will be visible on the part.
Zinc PlatingZinc plating, a process also known as galvanization, is the deposition of a thin layer of aluminum onto a metal component to provide a protective layer.
Nickel PlatedNickel electroplating a technique of electroplating a thin layer of nickel onto a metal object Electroless nickel plating, an auto-catalytic chemical technique used to deposit a layer of nickel-phosphorus or nickel-boron alloy on a solid workpiece.
Heat TreatedHeat treating can soften metal, to improve formability. It can make parts harder, to improve strength.
Black OxidedBlack Oxided is a conversion coating for ferrouns and non-ferrous materials
PhosphatePhosphate is a conversion coating for ferrouns and non-ferrous materials
Power CoatedPowder coating adds a thin layer of strong, wear and corrosion resistant protective polymer paint on the surface of a part. Available in a large range of colors.

See the examples for some of the projects.

cnc service
cnc parts
cnc parts
2

Aluminum Laser Cutting Part

Hooks

Steel sheet metal fabrication

Metal Stamping parts

cnc parts
cnc parts
cnc parts
cnc parts

Bending Parts

Sheet Metal

Laser Cutting Parts

Stainless Steel Sheet

What are the TOP 11 reasons to choose Worthy Hardware as your Sheet Metal Fabrication partner?

Reason 1-Instant quoting-12 hours for quotation

Reason 2-Fast samples delivery time-only 5-7 days including the finish

Reason 3-Reliable Quality Dedicated 3D Hubs team to ensure your parts consistently meet your quality expectations

Reason 4-Flexible communication-We also offer phone, email and chat support for any concerns or questions you may have.

Reason 5-Free samples with global shipping-If your order is over 1000$,we are glad to make the free samples for your testing.

Reason 6-Low MOQ-We have no MOQ limitation.

Reason 7-Design service--If you have the trouble in design your idea, our engineers could support

Reason 8-Stock service--If you would like to order more quantity but less space to store your goods,we could keep them for free.

Reason 9-Competitive prices but world class quality

Reason 10-For US customers, if you have the trouble importing from China, our US office could help you.

Reason 11-Our service contains cutting-bending-drilling-welding-pressing studs-polishing-finishing-assembly-packing.



Ready to get started with your next Sheet Metal Fabrication Project?

We make it easy to request a custom quote.



100+Material            Free Sample with Global Shipping           100% Quality Guaranteed

//]]>
